| System Parameter |
| Host Processor |
Embeded processor |
| Camera |
1/2.8″ 2MP CMOS high definition low illumination colorful |
| Angle of view |
D:180° H:160° V:82° |
| Focal length |
1.95 mm |
| WDR |
Support |
| Noise reduction |
Noise suppression and echo cancellation |
| Video encoding |
H.264 |
| Frame rate |
PAL:25 fps NTSC:30 fps |
| Audio encoding |
G.711 U |
| Video bit rate |
256K to 2M |
| Light compensation |
IR Supplement |
| Port |
| RS-485 Port |
1 |
| Alarm Output |
1 |
| Lock Control |
1 set |
| Door Status Detection |
1 set |
| Eoc |
1 set |
| Exit Button |
1 |
| Tamper Switch |
1 set |
| Network Interface |
1 |
| Power Output |
12V/100mA |
| Alarm Parameter |
| Tamper Alarm |
Support |
| Door Sensor Timeout Alarm |
Support |
| Alarm Iutput |
Support |
| Alarm Output |
Support |
| User Parameter |
| Audio Input |
Built-in Omnidirectional Microphone |
| Audio Output |
Built-in Loudspeaker |
| Status Indicator |
calling&communication&unlocked |
| Communication Methods |
Digital communication |
| Unlock Mode |
Remote unlocking |
| Auto Snapshot |
Support |
| Leave Videos or Text Messages |
Support |
| Storage |
Extended 64 G TF Card |
| WEB Configuration |
Support |
| Real-Time Monitor |
Support |
| Normal Parameter |
| Ingress Protection |
IP65 (Apply silica gel to gaps between the device and the wall. Liquid sodium silicate is recommended. For details, see the quick start guide.) |
| Network Update |
Online update |
| Housing material |
Alumimum |
| Power supply mode |
2-Wire Inteface or PoE |
| Rated Power |
12V DC |
| Rated Current |
1A |
| Installation method |
Supports surface mounted and flush mounted |
| Dimensions |
130 mm×96 mm×28.5 mm (5.1″×3.78″×1.1″) |
| Working Temperature |
-30°C to +60°C (-22°F to +140°F) |
| Working Humidity |
10%–90% |
| Atmospheric Pressure |
86kPa–106kPa |
| Power Consumption |
≤12W |
| Total Weight |
0.35kg/0.77lb |
| Environmental Requirement |
Outdoor |
