| Video parameters |
| Video compression standard |
H.264 |
| Audio parameters |
| Audio input |
Built-in omnidirectional microphone |
| Audio output |
Built-in loudspeaker |
| Audio compression bitrate |
64 Kbps |
| Audio quality |
Noise suppression and echo cancellation |
| Network parameters |
| Ethernet |
PoE, 10/100 Mbps self-adapted |
| Network protocol |
TCP/IP, RSTP |
| Device interfaces |
| Alarm input |
1 |
| Debugging port |
1 |
| General |
| Power supply |
IEEE802.3af, standard PoE
12 VDC
|
| Power consumption |
＜ 10 W |
| Working temperature |
-30° C to +50° C(-22° F to 122° F) |
| Working humidity |
10% to 90% |
| Impact protection |
IK 09 |
| Ingress protection level |
IP 65 |
| Dimensions (L x W x H) |
161.85 mm × 24.13 mm × 53.2 mm(6.37" × 1.02" × 2.09") |
| Installation |
Surface mounting |
